Product Details:
|
Condition: | New | Power: | 45kw |
---|---|---|---|
Production Capacity: | 0.3M3/m | Dimension(L*W*H): | 3840*1820*2080 |
Voltage: | 220V | After-sales Service Provided: | Free Spare Parts |
UNIQUE SELLING POINT: | Short Turning Radius | Hydraulic Cylinder Brand: | Huade |
Hydraulic Valve Brand: | Eaton | Hydraulic Pump Brand: | Parker |
High Light: | Mobility Kubota Skid Steer Loader,Mobility Skid Steer Loader,Hydraulic Motor Kubota Skid Steer Loader |
Product Paremeters
Model | JC45L | JC60L | JC65B | JC75(B/C) | JC100(B/C) | JC120B |
Model | JC45 | JC60 | JC65 | JC75 | JC100 | JC120 |
Overall operating height (mm) | 3670 | 3690 | 4000 | 4070 | 4070 | 4070 |
Height to bucket hinge pin (mm) | 2900 | 2920 | 3100 | 3150 | 3150 | 3150 |
height to top of cab (mm) | 2030 | 2050 | 2160 | 2160 | 2160 | 2160 |
Height to bottom of level bucket(mm) | 2733 | 2753 | 2933 | 2983 | 2983 | 2983 |
Overall length ithout bucket(mm) | 2450 | 2630 | 2750 | 2880 | 2880 | 2880 |
overall length with bucket(mm) | 3200 | 3380 | 3490 | 3580 | 3580 | 3580 |
Dumping angle at maximum height(° ) | 40 | 40 | 40 | 40 | 40 | 40 |
Dumping height(mm) | 2380 | 2400 | 2400 | 2450 | 2450 | 2450 |
Dumping reach(mm) | 700 | 750 | 750 | 700 | 700 | 700 |
Rollback o bucket on ground(° ) | 30 | 30 | 30 | 30 | 30 | 30 |
Rollback of bucket at full height(° ) | 104 | 104 | 104 | 104 | 104 | 104 |
Wheelbase(mm) | 991 | 991 | 1085 | 1115 | 1185 | 1185 |
Ground clearance(mm) | 185 | 205 | 205 | 205 | 205 | 205 |
Angleof departure(° ) | 20 | 20 | 20 | 20 | 20 | 20 |
Front turning radins without bucket(mm) | 1168 | 1198 | 1204 | 1250 | 1278 | 1278 |
Front tuning radius(mm) | 1958 | 1958 | 2030 | 2112 | 2144 | 2144 |
Rear tuning radius(mm) | 1630 | 1728 | 1706 | 1774 | 1857 | 1857 |
Rear axle to bumper (mm) | 1108 | 1208 | 1082 | 1082 | 1082 | 1082 |
Tread width,enterline to centerline (mm) | 1450 | 1500 | 1500 | 1500 | 1500 | 1500 |
Width (mm) | 1720 | 1800 | 1880 | 1880 | 1880 | 1880 |
Bucket width (mm) | 1740 | 1820 | 1880 | 1880 | 1880 | 1880 |
Operating load (kg) | 700 | 850 | 950 | 1050 | 1200 | 1500 |
Max Speed(km/h) | 12 | 12 | 12 | 12 | 12/18 | 12/18 |
Rated flux (L/min) | 62.5 | 75 | 80 | 80 | 80 | 80 |
Tire(track) model | 10-16.5 | 12-16.5 | 12-16.5 | 12-16.5 | 12-16.5 | 12-16.5 |
Rated power (Kw) | 37 | 45 | 55 | 55 | 74 | 103 |
Fuel tank capacity (L) | 60 | 60 | 75 | 75 | 90 | 90 |
self weight bucket (kg) | 2600 | 3000 | 3350 | 3500 | 3550 | 3600 |
Bucket capacity (m 3 ) | 0.4 | 0.45 | 0.5 | 0.5 | 0.55 | 0.55 |
