9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler

9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler
9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler 9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler 9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler

Large Image :  9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler

Product Details:
Place of Origin: China
Brand Name: World Equipment
Model Number: WEA50-4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10000-50000
Packaging Details: in nude
Delivery Time: 5-8Work days
Payment Terms: L/C, T/T
Supply Ability: 10 units per45days

9 Meter Telescopic Forklift Telehandler 5ton Telescopic Boom Handler

Description
Product Name: Telescopic Handler Forklift Rated Load: 5000KG
Max.Lifting Height: 7000mm Engine: Dongfeng Cummins
Advantage: Versatility, Stability, Maneuverability Color: Customsized
High Light:

9 Meter Telescopic Forklift Telehandler

,

9 Meter Telescopic Boom Handler

,

5ton Telescopic Boom Handler

Telescopic Forklift Telehandler Telehandler 5ton 9 Meter Telescopic Boom Handler Forklift Lo With CE Good Price WEA50-4



1. This telescopic forklift WEA50-4 which features the highest operation simplicity, safety and efficiency.

2. Using well-known brand diesel engine, strong-power, energy saving and environment protection,to meet the requirements of efficient operations

3. Double turbo hydraulic torque converter,stepless speed change. Single-lever control transmission system,with 2 speeds for forward and reverse gears, easier to operate.

4. Using maintenance-free battery,cab match with fan,radio,air conditioning,more comfortable and reliable.

5. The whole shape of the atmosphere,beautiful and smooth; luxury wide view cabin,low noise and good sealing.

6. This series models standard with electronic hand-brake, compared to the soft-axis handbrake, have a substantial increase in the operability,asthetics and sensi-tivity.



Items
Unit

Deviation
allowed
WEA25-4 WEA30-4 WEA35-4 WEA40-4 WEA50-2 WEA50H
基本参数Basicparameter Rated load kg - 2500 3000 3500 4000 5000 5000
Load center mm - 500 500 500 500 500 500
Load capacity@max.Forward reach kg - 1000 1250 1550 1800 1500 2000
Basic boom max.Lifting height mm ±1.5% 4850 4850 4850 4850 4500 5300
Max.Lifting height mm ±1.5% 7000 7000 7000 7000 7300 8800
Max.Horizontal reach mm ±1.5% 3350 3350 3350 3350 5700 5470
Min.Horizontal reach mm ±1.5% 930 930 930 930 1500 1270
Min.Ground clearance mm ±1.5% 400 400 400 400 310 310
Min.Turning radius(外轮中心 outer tyre
center)
mm ≤105% 6200 6200 6200 6200 6800 6800
Angle Boom frame upward angle . ±1.0 60 60 60 60 43 60
Boom frame downward angle . ±1.0 -11 -11 -11 -11 -14 -12
Operating weight kg ±5% 8200 8600 9000 9440 13000 13000
Overalldimension Length(with fork) mm ±2% 5730 5730 5730 5730 6288 5900
Width mm ±2% 2390 2390 2390 2390 2300 2350
Height mm ±2% 2485 2485 2485 2485 2715 2655
Wheel tread mm ±1% 1870 1870 1870 1870 1638/1845 1638/1845
Wheel base mm ±1% 2700 2700 2700 2700 2988 2988
Rated power/Rated turning speed KWirimin - 60/2000 60/2000 60/2000 60/2000 74/2200 74/2200
Drivingsystem Max.Travelling speed (unloaded) km/h ±10% 30 30 30 30 25 25
Grade ability % - ≥30% ≥30% 230% ≥30% 220% ≥20%
Tyre Front wheel(2pcs) - - 16/70-24 16/70-24 16/70-24 16/70-24 11.00-20 11.00-20
Rear wheel (2 pcs) - - 10.00
-20-16
10.00
-20-16
10.00
-20-16
10.00
-20-16
9.00-20 9.00-20
Engine Dongfeng Cummins   国二
National 2
4BTA3.9-C80II 4BTA3.9-C80II 4BTA3.9-C80II 4BTA3.9-C80II 4BTA3.9-C100II 4BTA3.9-C100II
  国三
National 3
QSB3.9-C80 QSB3.9-C80 QSB3.9-C80 QSB3.9-C80 QSB3.9-C100 QSB3.9-C100
