Product Details:
|
| Brand: | WORLD | Type: | Backhoe Loader |
|---|---|---|---|
| After-sales Service Provided: | Online Support | Bucket Capacity: | 1m3 |
| Rated Power: | 75kw | Operating Weight: | 8200kg |
| Color: | Yellow | Warranty: | 1 Year |
| Dumping Height: | 2742mm | Max Digging Depth: | 4082/4500mm |
| Country: | China | ||
| High Light: | Compact Structure Mini Backhoe Loader,Compact Structure Mini Tractor Backhoe Loader,Weichai Engine Mini Backhoe Loader |
||
1.Backhoe loader’s exclusive use chassis, compact structure, rationally distributed.
2.Equipped with totally enclosed ROPS cab with broad vision and attractive outline design, it is comfort and reasonable to control the machine with its full range and humanization design in control system.
3.Adopt the Yuchai/Weichai engine, which is green environmental protection, high power, less fuel consumption, high working efficiency, low use cost.
4.Excellent excavating/loading performance brings the best return on customer’s investment.
5.Optional two-wheel drive or four-wheel drive could meet customer’s requirement.
Product parameters
| Item | Data | Item | Date |
| Power | 75KW | Dimension | 5910*2268*3760mm |
| Bucket capacity | 1.4M3 | Bucket Dumping Height | 2742mm |
| Backhoe Capacity | 0.3M3 | Bucket Dumping Distance | 1062mm |
| Overall Operating Weight | 7460KG | Max. Pulling Force | 39KN |
| breakout force | 38kN | Tire Size | 16/70-20 |
| Wheel base | 2250mm | Total displacement | 3.9L |
| Thread | 1400mm | Swing Angle of Excavator Grab | 190° |
| Loading Lifting Capacity | 2500KG | Min. Ground Clearance | 300mm |
