Product Details:
|
| Condition: | New | Power: | 45kw |
|---|---|---|---|
| Production Capacity: | 0.3M3/m | Dimension(L*W*H): | 3840*1820*2080 |
| Voltage: | 220V | After-sales Service Provided: | Free Spare Parts |
| UNIQUE SELLING POINT: | Short Turning Radius | Hydraulic Cylinder Brand: | Huade |
| Hydraulic Valve Brand: | Eaton | Hydraulic Pump Brand: | Parker |
| Highlight: | Various Accessories Skid Steer Loader,45kw Skid Steer Loader |
||
World equipment is dedicated to provide our clients with genuine spare parts with the highest quality, exact fitness and appropriate function. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are. Please submit your spare parts request to us, and list products name, model, equipment serial number, description of required parts. We guarantee that your request will be handled quickly and appropriately.
Product Paremeters
| Model | JC45L | JC60L | JC65B | JC75(B/C) | JC100(B/C) | JC120B |
| Model | JC45 | JC60 | JC65 | JC75 | JC100 | JC120 |
| Overall operating height (mm) | 3670 | 3690 | 4000 | 4070 | 4070 | 4070 |
| Height to bucket hinge pin (mm) | 2900 | 2920 | 3100 | 3150 | 3150 | 3150 |
| height to top of cab (mm) | 2030 | 2050 | 2160 | 2160 | 2160 | 2160 |
| Height to bottom of level bucket(mm) | 2733 | 2753 | 2933 | 2983 | 2983 | 2983 |
| Overall length ithout bucket(mm) | 2450 | 2630 | 2750 | 2880 | 2880 | 2880 |
| overall length with bucket(mm) | 3200 | 3380 | 3490 | 3580 | 3580 | 3580 |
| Dumping angle at maximum height(° ) | 40 | 40 | 40 | 40 | 40 | 40 |
| Dumping height(mm) | 2380 | 2400 | 2400 | 2450 | 2450 | 2450 |
| Dumping reach(mm) | 700 | 750 | 750 | 700 | 700 | 700 |
| Rollback o bucket on ground(° ) | 30 | 30 | 30 | 30 | 30 | 30 |
| Rollback of bucket at full height(° ) | 104 | 104 | 104 | 104 | 104 | 104 |
| Wheelbase(mm) | 991 | 991 | 1085 | 1115 | 1185 | 1185 |
| Ground clearance(mm) | 185 | 205 | 205 | 205 | 205 | 205 |
| Angleof departure(° ) | 20 | 20 | 20 | 20 | 20 | 20 |
| Front turning radins without bucket(mm) | 1168 | 1198 | 1204 | 1250 | 1278 | 1278 |
| Front tuning radius(mm) | 1958 | 1958 | 2030 | 2112 | 2144 | 2144 |
| Rear tuning radius(mm) | 1630 | 1728 | 1706 | 1774 | 1857 | 1857 |
| Rear axle to bumper (mm) | 1108 | 1208 | 1082 | 1082 | 1082 | 1082 |
| Tread width,enterline to centerline (mm) | 1450 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Width (mm) | 1720 | 1800 | 1880 | 1880 | 1880 | 1880 |
| Bucket width (mm) | 1740 | 1820 | 1880 | 1880 | 1880 | 1880 |
| Operating load (kg) | 700 | 850 | 950 | 1050 | 1200 | 1500 |
| Max Speed(km/h) | 12 | 12 | 12 | 12 | 12/18 | 12/18 |
| Rated flux (L/min) | 62.5 | 75 | 80 | 80 | 80 | 80 |
| Tire(track) model | 10-16.5 | 12-16.5 | 12-16.5 | 12-16.5 | 12-16.5 | 12-16.5 |
| Rated power (Kw) | 37 | 45 | 55 | 55 | 74 | 103 |
| Fuel tank capacity (L) | 60 | 60 | 75 | 75 | 90 | 90 |
| self weight bucket (kg) | 2600 | 3000 | 3350 | 3500 | 3550 | 3600 |
| Bucket capacity (m 3 ) | 0.4 | 0.45 | 0.5 | 0.5 | 0.55 | 0.55 |
