Product Details:
|
| Model Number: | B165, B220, B320 | Machine Weight: | 17000kg |
|---|---|---|---|
| Dozing Capacity: | 5m3 | Moving Type: | Crawler Bulldozer |
| Dimension(Long * Breadth * High): | 5140*3388*3032 | Color: | Cat Yellow |
| High Light: | Crawler Mounted Bulldozer D85,D85 Small Crawler Dozer,Electronic Lock Crawler Mounted Bulldozer |
||
Main Features
1. 165 hp Bulldozer (165 hp dozer) has attractive appearance and a strong sense of the times.
2. High engine power, large output torque, low oil-consumption, reliable.
3. Hydraulic transmission, automatic speed regulation, gear shifting without stopping the machine.
4. Three components on single element single stage torque converter, high efficiency, large capacity.
5. The new ROPS-FOPS rollover and falling object protection device is beautiful and practical.
6, novel hexagonal cab, more open vision, better ventilation, better sealing effect.
7. The final transmission adopts triangular spline and drum gear, which improves the bearing uniformity and smoothness of the transmission parts and prolongs the service life.
8, the new earth-moving device is practical and durable, and the shovel capacity is larger.
9, the new three-level alarm electronic monitoring device electromechanical integration, electronic monitoring and instrument display, three-level alarm.
10, the control design is people-oriented. Handles are distributed on both sides for easier operation.
11. Working equipment adopts electronic lock, more convenient, more reliable.
12. Diverse optional devices: ROPS-FOPS cabin, ordinary cabin, cabin with air conditioner, heater, the anther starting aid,
angle and straight blade push broach, U-blade spade, environmental sanitation spade etc.
| Model | B165 | B220 | B320 |
| Engine Rated power(kw/rpm) | 131/1850 kw/rpm | 175/1800 | 257/2000 |
| Displacement(L) | 9.726 | 14.01 | 14.01 |
| Max.torque(N.m/rpm) | 830/1000-1200 | 1030/1250 | 1440/1400 |
| Operating weight(Kg) | 17000 | 23500 | 37200 |
| Dimension(no ripper)(mm) | 5140×3388×3032 | 5492×3726×3742 | 6885×4128×3645 |
| Min ground clearance(mm) | 405 | 405 | 500 |
| Track shoe width(mm) | 510 | 560/610/660 | 560/660/760 |
| Dozing capacity( m³) | 4.55 | 6.4 | 10 |
| Max drop below ground(mm) | 540 | 540 | 560 |
| Max pressure(MPa) | 14 | 14 | 14 |
| Max tractor force(KN) | 146 | 202 | 280 |
| Grade ability(°) | 30 | 30 | 30 |
| Forward(km/h) | 3.29/5.82/9.63 | 3.6/6.5/11.2 | 3.6/6.6/11.5 |
| Reverse(km/h) | 4.28/7.59/12.53 | 4.3/7.7/13.2 | 4.4/7.8/13.5 |
