China WORLD Dozer For Mining Heavy Equipment Dozer crawler type working equipment equal to CAT D6 Bulldozer

China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer

Large Image :  China WORLD Dozer For Mining Heavy Equipment Dozer crawler type working equipment equal to CAT D6 Bulldozer

Product Details:
Place of Origin: CHINA
Brand Name: WEA
Model Number: B165
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: usd66000/unit-usd75000/unit
Packaging Details: roro ship or 40FR
Delivery Time: 35 working days
Payment Terms: D/P, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 units per year

China WORLD Dozer For Mining Heavy Equipment Dozer crawler type working equipment equal to CAT D6 Bulldozer

Description
Machine Weight: 17000kg Dozing Capacity: 5m3
Model Number: B165, B220, B320 Moving Type: Crawler Type
Dimension(Long * Breadth * High): 5140*3388*3032 Brand: WORLD
Country: China

Product Description
China WORLD Dozer For Mining Heavy Equipment Dozer crawler type working equipment equal to CAT D6 Bulldozer
Product Overview

B165 B220 B320 DOZER

High engine power, large output torque, low oil-consumption, reliableHigh engine power, large output torque, low oil-consumption, reliable
FEATURES AT A GLANCE
Hydraulic transmission, automatic speed regulation, gear shifting without stopping the machine. Three components on single element single stage torque converter, high efficiency, large capacity.

Main Features

1, the engine power reserve coefficient is high, output torque, low fuel consumption, reliable use.
2, hydraulic transmission, automatic speed regulation, no stop shift.
3, the final transmission using hard tooth surface drum repair tooth gear, large bearing capacity and long service life.
4, the moving device can lift and roll, the control of hydraulic servo mechanism, easy to operate. Strength wear-resisting push blade, high bearing capacity and good wear resistance.
5, the new steering hydraulic control valve, so that the operation is easier, reduce labor intensity, improve efficiency.
6, novel and beautiful hexagonal cab, more open vision, better ventilation, sealing effect is better.
7, the new three-level alarm electronic monitoring device electromechanical integration, electronic monitoring and instrument display, three-level alarm.
8. There are many optional devices: U-shaped shovel, straight tilt shovel, Angle shovel, air conditioning cab, driving shed, ROPS-FOPS rollover and falling object protection device, three-tooth soil breaker, single-tooth soil breaker, heating pot device, heating device, ether starting device, etc.
9. There are many variant products, such as belt shifting machine and pipe hanging machine.


Product Parameters
Model B165 B220 B320
Engine Rated power(kw/rpm) 131/1850 kw/rpm 175/1800 257/2000
Displacement(L) 9.726 14.01 14.01
Max.torque(N.m/rpm) 830/1000-1200 1030/1250 1440/1400
Operating weight(Kg) 17000 23500 37200
Dimension(no ripper)(mm) 5140×3388×3032 5492×3726×3742 6885×4128×3645
Min ground clearance(mm) 405 405 500
Track shoe width(mm) 510 560/610/660 560/660/760
Dozing capacity( m³) 4.55 6.4 10
Max drop below ground(mm) 540 540 560
Max pressure(MPa) 14 14 14
Max tractor force(KN) 146 202 280
Grade ability(°) 30 30 30
Forward(km/h) 3.29/5.82/9.63 3.6/6.5/11.2 3.6/6.6/11.5
Reverse(km/h) 4.28/7.59/12.53 4.3/7.7/13.2 4.4/7.8/13.5

Product Photos
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 0
CABIN INSDE
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 1

CABIN
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 2

OPERATOR SEAT
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 3

PRODUCT CONFIGURATION
TORQUE CONVENTOR
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 4

ICARRIER
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 5

SUPPORT
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 6

SALES AND SERVICE NETWORK
China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 7


China WORLD Dozer For Mining Heavy Equipment Dozer  crawler type working equipment equal to CAT D6 Bulldozer 8
