Product Details:
|
| Condition: | New | Bucket Capacity: | 0.6 M3 |
|---|---|---|---|
| Moving Type: | Wheel Excavator | After-sales Service Provided: | Online Support |
| Warranty: | 1 Year / 2000 Working Hours | Machine Weight: | 14100kg |
| Color: | Yellow | Engine: | YUCHAI/YC4D125 |
| Keywords: | Wheel Excevator | Product Name: | Wheel Excavator |
| Engine Power: | 92kw(125HP) | Type: | Hydraulic Wheel Excavator,mini Wheeled Excavator,mini Farm Machinery |
| High Light: | Small Bucket Wheeled Mini Excavator,Hydraulic Control Wheeled Mini Excavator,Small Bucket Earth Moving Machine |
||
MAIN FEATURES
The breaking pipeline equipped improve the working performance .
TECHNICAL PARAMETERS
| ENGINE | |
| Emission Standard | China Stage III |
| Make /Model | YUCHAI/YC4D125 |
| Power /Rotation speed | 92kw(125HP)@2200rpm |
| Number of cylinder | 4 |
| DRIVING SYSTEM | |
| Maximum Travel speed | 25km/h |
| Tire model/Number of tires | 9.00-20/8 |
| Driving type | Hydraulic controlling |
| Steering type | Steering wheel |
| TRANSMISSION | |
| Type | Free shift(Stepless gear box) |
| BRAKE SYSTEM | |
| Driving brake(Front axle) | Hydraulic brake(brake caliper) |
| Driving brake(Rear axle) | Hydraulic brake(brake caliper) |
| Parking brake | Brake pedal lock |
| Emergency brake | Foot brake |
| PERFORMANCE PARAMETER | |
| Standard Bucket capacity | 0.6m³ |
| Swing speed | 12rpm |
| Maximum Grade ability | 25° |
| Maximum Bucket digging force | 91KN |
| Maximum Arm digging force | 55KN |
| Hydraulic system pressure | 32Mpa |
| Machine weight | 14100kg |
| Fuel tank | 252L |
| Hydraulic oil tank | 160L |
| Engine oil capacity | 11L |
| MACHINE SIZE | |
| Overall dimension (L*W*H) | 7520mm*2570mm*3425mm |
| Height of cabin | 3015mm |
| Wheel base/Tread | 2600mm/1944mm |
| Minimum Ground clearance | 350mm |
| Swing radius at tail | 2332mm |
| WORKING RANGE | |
| Maximum Digging height | 8930mm |
| Maximum Dumping height | 6520mm |
| Maximum Digging depth | 4750mm |
| Maximum Vertical digging depth | 4200mm |
| Maximum Digging radius | 8000mm |
| Minimum swing radius | 2445mm |
| Maximum lifting height of dozer blade | 400mm |
| Maximum cutting depth of dozer blade | 100mm |
